Cattin C54 Movement Specifications, Beat Rate & Dimensions |
|
Technical Caliber Datasheet
| Manufacturer | Cattin |
| Caliber Reference | Cattin C54 |
| Movement Type | Manual |
| Diameter (Lignes) | — |
| Diameter (mm) | 25.95 mm |
| Height / Thickness | 5.4 mm |
| Jewel Count | 21 Jewels |
| Beat Rate / Frequency | 18,000 BPH |
| Lift Angle | 51° |
| Power Reserve | 38 hours |
| Escapement | Pin Lever |
| Production Period | 1955 |
Historical & Mechanical Notes
The Cattin C54 is a celebrated example of vintage precision engineering. Featuring 21 jewels and operating at 18,000 BPH, surviving examples are prized by collectors and restorers. For further technical reference on vintage watch movements, consult the Ranfft Watch Movement Archive.
