Minerva 9CH Movement Specifications, Beat Rate & Dimensions |
|
Technical Caliber Datasheet
| Manufacturer | Minerva |
| Caliber Reference | Minerva 9CH |
| Movement Type | Manual |
| Diameter (Lignes) | — |
| Diameter (mm) | 42.65 mm |
| Height / Thickness | 7.6 mm |
| Jewel Count | 17 Jewels |
| Beat Rate / Frequency | 18,000 BPH |
| Lift Angle | 51° |
| Power Reserve | 38 hours |
| Escapement | Swiss Lever |
| Production Period | 1908 |
Historical & Mechanical Notes
The Minerva 9CH is a celebrated example of vintage precision engineering. Featuring 17 jewels and operating at 18,000 BPH, surviving examples are prized by collectors and restorers. For authentic restored timepieces and bespoke pocket-to-wrist conversions, visit pocket watch conversion into wristwatch.
